Hier vindt u alle beschikbare onderdelen en tekeningen van de 'Milwaukee 4000469677 ( M18FMS305-0 )'. Vanaf hier kunt u direct alle gewenste onderdelen bestellen. Vele onderdelen moeten bij de fabrikant besteld worden, dit duurt afhankelijk van het merk, één tot vier weken. Alle informatie die we hebben, staat op onze website, wij kunnen u geen advies geven over wat u nodig heeft, daarvoor zult u de machine ter reparatie in moeten leveren. Let bij het bestellen op het volgende:
Tekeningen van de Milwaukee 4000469677 ( M18FMS305-0 )
Onderdelen lijst van de Milwaukee 4000469677 ( M18FMS305-0 )
| Pos. | Omschrijving | Prijs excl. BTW | Prijs incl. BTW | |
| Getoonde prijzen zijn inclusief btw | ||||
| SET SCREW | ||||
| 0013 | 4931454626 | 1.80 | 2.18 | |
| SCREW | ||||
| 0018 | 4931472434 | 1.80 | 2.18 | |
| PLATE | ||||
| 0019 | 4931472435 | 5.40 | 6.53 | |
| BEARING | ||||
| 0024 | 4931472436 | 9.00 | 10.89 | |
| PIN | ||||
| 0030 | 4931472437 | 1.80 | 2.18 | |
| SCREW | ||||
| 0035 | 4931472438 | 4.49 | 5.43 | |
| SCREW | ||||
| 0038 | 4931465028 | 1.80 | 2.18 | |
| SCREW | ||||
| 0050 | 4931472439 | 1.80 | 2.18 | |
| SCREW | ||||
| 0058 | 4931454631 | 1.80 | 2.18 | |
| SCREW | ||||
| 0059 | 4931454628 | 1.80 | 2.18 | |
| SCREW | ||||
| 0066 | 4931461999 | 1.80 | 2.18 | |
| DIRECT,DUST CHUTE | ||||
| 0074 | 4931472440 | 14.40 | 17.42 | |
| DUST EXTRACTION | ||||
| 0075 | 4931465022 | 5.40 | 6.53 | |
| BOLT | ||||
| 0086 | 4931454656 | 5.40 | 6.53 | |
| SCREW | ||||
| 0091 | 4931472441 | 1.80 | 2.18 | |
| SCREW | ||||
| 0092 | 4931472442 | 1.80 | 2.18 | |
| SPRING | ||||
| 0093 | 4931472443 | 9.00 | 10.89 | |
| LOCKING BOLT | ||||
| 0094 | 4931472444 | 10.80 | 13.07 | |
| LOCKING PIECE | ||||
| 0095 | 4931472445 | 5.40 | 6.53 | |
| SCREW | ||||
| 0096 | 4931472446 | 1.80 | 2.18 | |
| WASHER | ||||
| 0097 | 4931472447 | 1.80 | 2.18 | |
| SLIDER | ||||
| 0098 | 4931472448 | 9.00 | 10.89 | |
| SPRING | ||||
| 0099 | 4931472449 | 1.80 | 2.18 | |
| BEARING BOLT | ||||
| 0100 | 4931461974 | 17.42 | 21.08 | |
| SPRING | ||||
| 0101 | 4931454651 | 4.49 | 5.43 | |
| SPRING | ||||
| 0104 | 4931454659 | 1.80 | 2.18 | |
| SCREW | ||||
| 0105 | 4931465017 | 1.80 | 2.18 | |
| LOCK COMPLETE | ||||
| 0106 | 4931465015 | 4.49 | 5.43 | |
| POINTER | ||||
| 0109 | 4931472450 | 4.49 | 5.43 | |
| PLATE | ||||
| 0111 | 4931472451 | 12.60 | 15.25 | |
| SCREW | ||||
| 0117 | 4931472452 | 1.80 | 2.18 | |
| SCREW | ||||
| 0120 | 4931472453 | 1.80 | 2.18 | |
| THREADED BOLT | ||||
| 0122 | 4931461997 | 8.09 | 9.79 | |
| WASHER | ||||
| 0123 | 4931465009 | 1.80 | 2.18 | |
| KNOB HANDLE | ||||
| 0124 | 4931472454 | 26.93 | 32.59 | |
| CLAMPING SCREW | ||||
| 0125 | 4931461984 | 5.40 | 6.53 | |
| RUBBER FOOT | ||||
| 0126 | 4931454668 | 1.80 | 2.18 | |
| SCALE | ||||
| 0127 | 4931472455 | 82.37 | 99.67 | |
| SCREW | ||||
| 0128 | 4931461980 | 5.40 | 6.53 | |
| SCREW | ||||
| 0129 | 4931461982 | 5.40 | 6.53 | |
| GRIP | ||||
| 0130 | 4931472456 | 41.18 | 49.83 | |
| BEARING COVER | ||||
| 0132 | 4931454662 | 79.20 | 95.83 | |
| YOKE | ||||
| 0133 | 4931472457 | 15.84 | 19.17 | |
| ALLEN KEY | ||||
| 0135 | 4931461976 | 5.40 | 6.53 | |
| STOP | ||||
| 0136 | 4931472458 | 136.22 | 164.83 | |
| COVER | ||||
| 0138 | 4931454667 | 5.40 | 6.53 | |
| STOP | ||||
| 0139 | 4931472459 | 93.46 | 113.09 | |
| STOP | ||||
| 0140 | 4931472460 | 93.46 | 113.09 | |
| SCREW | ||||
| 0147 | 4931454635 | 1.80 | 2.18 | |
| RUBBER BUFFER | ||||
| 0149 | 4931472461 | 1.80 | 2.18 | |
| PIN | ||||
| 0156 | 4931472462 | 4.49 | 5.43 | |
| O-RING | ||||
| 0157 | 4931454636 | 1.80 | 2.18 | |
| SPINDLE LOCK | ||||
| 0158 | 4931454637 | 5.40 | 6.53 | |
| STOP | ||||
| 0159 | 4931454638 | 4.49 | 5.43 | |
| SUCTION SLEEVE | ||||
| 0163 | 4931465000 | 9.00 | 10.89 | |
| POINTER | ||||
| 0180 | 4931472463 | 4.49 | 5.43 | |
| POINTER | ||||
| 0181 | 4931472464 | 4.49 | 5.43 | |
| WASHER | ||||
| 0185 | 4931465012 | 1.80 | 2.18 | |
| WORK LAMP | ||||
| 0194 | 4931472465 | 49.10 | 59.41 | |
| SCREW | ||||
| 0195 | 4931472466 | 1.80 | 2.18 | |
| HOLDING BRACKET | ||||
| 0210 | 4931472467 | 17.42 | 21.08 | |
| HOLDING-DOWN DEVICE | ||||
| 0211 | 4931472468 | 125.14 | 151.42 | |
| GUARD | ||||
| 0212 | 4931472469 | 109.30 | 132.25 | |
| TURNING KNOB | ||||
| 0213 | 4931472470 | 14.40 | 17.42 | |
| FLANGE | ||||
| 0214 | 4931472471 | 42.77 | 51.75 | |
| CATCH LEVER | ||||
| 0216 | 4931472472 | 15.84 | 19.17 | |
| LOCKING BOLT | ||||
| 0217 | 4931472473 | 17.42 | 21.08 | |
| BRACKET | ||||
| 0218 | 4931472474 | 15.84 | 19.17 | |
| PIN | ||||
| 0219 | 4931472475 | 4.49 | 5.43 | |
| HANDLE | ||||
| 0220 | 4931472476 | 20.59 | 24.91 | |
| SPINDLE | ||||
| 0221 | 4931472477 | 69.70 | 84.34 | |
| COVER | ||||
| 0223 | 4931472478 | 45.94 | 55.59 | |
| STOP | ||||
| 0224 | 4931472479 | 55.44 | 67.08 | |
| SCREW | ||||
| 0225 | 4931472480 | 10.80 | 13.07 | |
| ELECTRONIC | ||||
| 0226 | 4931472481 | 598.75 | 724.49 | |
| GEAR BOX | ||||
| 0227 | 4931472482 | 204.34 | 247.25 | |
| SPINDLE LOCK | ||||
| 0228 | 4931472483 | 12.60 | 15.25 | |
| SCREW | ||||
| 0229 | 4931472484 | 137.81 | 166.75 | |
| HINGE PIECE | ||||
| 0230 | 4931472485 | 259.78 | 314.33 | |
| ROTOR | ||||
| 0231 | 4931472486 | 278.78 | 337.32 | |
| DEPTH GAUGE | ||||
| 0232 | 4931472487 | 15.84 | 19.17 | |
| SHAFT | ||||
| 0233 | 4931472488 | 83.95 | 101.58 | |
| DIAPHRAGM | ||||
| 0234 | 4931472489 | 69.70 | 84.34 | |
| TRIGGER | ||||
| 0235 | 4931472490 | 12.60 | 15.25 | |
| SCREW | ||||
| 0236 | 4931472491 | 17.42 | 21.08 | |
| HANDLE | ||||
| 0237 | 4931472492 | 55.44 | 67.08 | |
| RATING PLATE | ||||
| 0238 | 4931472493 | 4.49 | 5.43 | |
| COVER | ||||
| 0239 | 4931472494 | 12.60 | 15.25 | |
| CAP | ||||
| 0240 | 4931472495 | 57.02 | 68.99 | |
| BRACKET | ||||
| 0241 | 4931472496 | 278.78 | 337.32 | |
| LOCKING PIECE | ||||
| 0242 | 4931472497 | 14.40 | 17.42 | |
| PIN | ||||
| 0243 | 4931472498 | 12.60 | 15.25 | |
| CATCH LEVER | ||||
| 0244 | 4931472499 | 15.84 | 19.17 | |
| CATCH LEVER | ||||
| 0245 | 4931472500 | 15.84 | 19.17 | |
| SWITCH | ||||
| 0247 | 4931472501 | 9.00 | 10.89 | |
| DOOR | ||||
| 0248 | 4931472502 | 7.20 | 8.71 | |
| DUST BOX ASSY | ||||
| 0249 | 4931472503 | 49.10 | 59.41 | |
| SWITCH | ||||
| 0250 | 4931472504 | 76.03 | 92.00 | |
| COVER | ||||
| 0251 | 4931472505 | 57.02 | 68.99 | |
| SCREW | ||||
| 0252 | 4931472506 | 1.80 | 2.18 | |
