Hier vindt u alle beschikbare onderdelen en tekeningen van de 'Milwaukee 4000400221 ( 5380-20 )'. Vanaf hier kunt u direct alle gewenste onderdelen bestellen. Vele onderdelen moeten bij de fabrikant besteld worden, dit duurt afhankelijk van het merk, één tot vier weken. Alle informatie die we hebben, staat op onze website, wij kunnen u geen advies geven over wat u nodig heeft, daarvoor zult u de machine ter reparatie in moeten leveren. Let bij het bestellen op het volgende:
Tekeningen van de Milwaukee 4000400221 ( 5380-20 )
Onderdelen lijst van de Milwaukee 4000400221 ( 5380-20 )
| Pos. | Omschrijving | Prijs excl. BTW | Prijs incl. BTW | |
| Getoonde prijzen zijn inclusief btw | ||||
| Niet meer leverbaar | ||||
| 0004 | 4931623683 | |||
| Niet meer leverbaar | ||||
| 0106 | 4931400227 | |||
| FAN | ||||
| 0107 | 4931342793 | 5.40 | 6.53 | |
| GROOVED BALL BEAR, | ||||
| 0108 | 4931368037 | 5.40 | 6.53 | |
| Ball Bearing | ||||
| 0109 | 4931624662 | 9.00 | 10.89 | |
| SLEEVE | ||||
| 0110 | 4931302748 | 4.49 | 5.43 | |
| BEARING COVER | ||||
| 0111 | 4931267585 | 4.49 | 5.43 | |
| SCREW | ||||
| 0112 | 4931612817 | 1.80 | 2.18 | |
| AIR DEFLECTOR RING | ||||
| 0113 | 4931380470 | 7.20 | 8.71 | |
| HOLDING-DOWN DEVICE | ||||
| 0114 | 4931332524 | 5.40 | 6.53 | |
| WIRE | ||||
| 0115 | 4931623320 | 1.80 | 2.18 | |
| Niet meer leverbaar | ||||
| 0116 | 4931623321 | |||
| WIRE | ||||
| 0118 | 4931625509 | 1.80 | 2.18 | |
| BRUSH HOLDER | ||||
| 0120 | 4931382268 | 5.40 | 6.53 | |
| ROLL | ||||
| 0121 | 4931623123 | 4.49 | 5.43 | |
| CENTERING LEDGE | ||||
| 0123 | 4931326971 | 4.49 | 5.43 | |
| CABLE COLLAR | ||||
| 0125 | 4931256500 | 5.40 | 6.53 | |
| SCREW | ||||
| 0126 | 4931624516 | 1.80 | 2.18 | |
| SCREW N874101-1 SHR H-K4X18 T15 | ||||
| 0127 | 4931624515 | 1.80 | 2.18 | |
| WIRE | ||||
| 0131 | 4931624531 | 1.80 | 2.18 | |
| Niet meer leverbaar | ||||
| 0135 | 4931400228 | |||
| DRILL SPINDLE | ||||
| 0201 | 4931409811 | 12.60 | 15.25 | |
| DISC | ||||
| 0206 | 4931621809 | 5.40 | 6.53 | |
| PRESSURE SPRING | ||||
| 0207 | 4931267406 | 5.40 | 6.53 | |
| BALL BEARING | ||||
| 0208 | 4931891058 | 9.00 | 10.89 | |
| PERCUSSION SLEEVE | ||||
| 0209 | 4931267571 | 3.60 | 4.36 | |
| SEAL RING | ||||
| 0210 | 4931267522 | 5.40 | 6.53 | |
| LOCKING RING | ||||
| 0211 | 4931890311 | 5.40 | 6.53 | |
| DISC | ||||
| 0212 | 4931621647 | 1.80 | 2.18 | |
| DRILL SPINDLE WHEEL | ||||
| 0213 | 4931426230 | 9.00 | 10.89 | |
| SHIFT RING COMPL, | ||||
| 0214 | 4931307130 | 15.84 | 19.17 | |
| DRILL SPINDLE WHEEL | ||||
| 0215 | 4931426231 | 9.00 | 10.89 | |
| DISC | ||||
| 0216 | 4931621679 | 5.40 | 6.53 | |
| PIN | ||||
| 0217 | 4931805526 | 5.40 | 6.53 | |
| SWITCH LEVER | ||||
| 0218 | 4931339525 | 5.40 | 6.53 | |
| RETAINING SPRING | ||||
| 0219 | 4931307118 | 5.40 | 6.53 | |
| SWITCH LEVER | ||||
| 0220 | 4931267576 | 5.40 | 6.53 | |
| PIN | ||||
| 0221 | 4931621731 | 5.40 | 6.53 | |
| SCREW | ||||
| 0222 | 4931364667 | 1.80 | 2.18 | |
| WASHER | ||||
| 0226 | 4931623164 | 1.80 | 2.18 | |
| PIN | ||||
| 0228 | 4931621770 | 5.40 | 6.53 | |
| REDUCTION GEAR | ||||
| 0229 | 4931342887 | 57.02 | 68.99 | |
| PIN | ||||
| 0234 | 4931621732 | 5.40 | 6.53 | |
| Ball | ||||
| 0235 | 4931805390 | 1.80 | 2.18 | |
| BALL | ||||
| 0236 | 4931621735 | 1.80 | 2.18 | |
| BALL | ||||
| 0237 | 4931621736 | 1.80 | 2.18 | |
| BALL | ||||
| 0238 | 4931621737 | 1.80 | 2.18 | |
| DISC | ||||
| 0240 | 4931621715 | 5.40 | 6.53 | |
| Niet meer leverbaar | ||||
| 0410 | 4931400821 | |||
| DEPTH GAUGE | ||||
| 0605 | 4931384434 | 5.40 | 6.53 | |
| CARRYING CASE | ||||
| 0700 | 4931387084 | 46.74 | 56.56 | |
| Tandkransboorhouder 1,5 - 13 mm, 1/2 x 20 | ||||
| 0701 | 4932267980 | 13.66 | 16.53 | |
| Zijhandgreep | ||||
| 0705 | 4932373725 | 9.93 | 12.02 | |
| Locking Screw | ||||
| 0801 | 4931401643 | 1.80 | 2.18 | |
| Niet meer leverbaar | ||||
| 1100 | 4931400820 | |||
| Niet meer leverbaar | ||||
| 1101 | 4931400292 | |||
| HANDLE COVER | ||||
| 1102 | 4931364919 | 4.49 | 5.43 | |
| HANDLE | ||||
| 1103 | 4931400450 | 9.00 | 10.89 | |
| PROTECTIVE CAP | ||||
| 1107 | 4931347299 | 4.49 | 5.43 | |
| Niet meer leverbaar | ||||
| 1200 | 4931400234 | |||
| CARBON BRUSH SET | ||||
| 1201 | 4931392595 | 14.40 | 17.42 | |
| RUBBER SLEEVE | ||||
| 1202 | 4931254368 | 1.80 | 2.18 | |
| DAMPING ELEMENT | ||||
| 1203 | 4931342803 | 4.49 | 5.43 | |
| SCREW | ||||
| 1204 | 4931621772 | 1.80 | 2.18 | |
| CONNECTOR | ||||
| 1205 | 4931307924 | 4.49 | 5.43 | |
| HOLDING-DOWN DEVICE | ||||
| 1206 | 4931409768 | 5.40 | 6.53 | |
| GASKET | ||||
| 1207 | 4931267583 | 4.49 | 5.43 | |
| CABLE ENTRY SLEEVE | ||||
| 1208 | 4931359575 | 5.40 | 6.53 | |
| COUPLING SET | ||||
| 1300 | 4931347492 | 33.26 | 40.24 | |
