Hier vindt u alle beschikbare onderdelen en tekeningen van de 'Makita SG1250'. Vanaf hier kunt u direct alle gewenste onderdelen bestellen. Vele onderdelen moeten bij de fabrikant besteld worden, dit duurt afhankelijk van het merk, één tot vier weken. Alle informatie die we hebben, staat op onze website, wij kunnen u geen advies geven over wat u nodig heeft, daarvoor zult u de machine ter reparatie in moeten leveren. Let bij het bestellen op het volgende:
Tekeningen van de Makita SG1250
Onderdelen lijst van de Makita SG1250
| Pos. | Omschrijving | Prijs excl. BTW | Prijs incl. BTW | |
| Getoonde prijzen zijn inclusief btw | ||||
| Tapschroef 4x18 | ||||
| 001 | 265A48-7@141 | 0.90 | 1.09 | |
| Handgreep set | ||||
| 002 | 183692-1@141 | 23.75 | 28.74 | |
| Tapschroef 4x18 | ||||
| 003 | 265A48-7@141 | 0.90 | 1.09 | |
| Schroef 5x40 | ||||
| 004 | 911263-2@141 | 0.83 | 1.00 | |
| Schakelaar afdekkap | ||||
| 005 | 687113-0@141 | 0.83 | 1.00 | |
| Geen informatie beschikbaar, niet bestelbaar | ||||
| 006 | 651428-1@141 | |||
| Schakelaarhouder | ||||
| 007 | 632945-0@141 | 9.52 | 11.52 | |
| Klemstrip | ||||
| 008 | 687053-2@141 | 0.83 | 1.00 | |
| Tapschroef 4x18 | ||||
| 009 | 265A48-7@141 | 0.90 | 1.09 | |
| Kabeltule 8-110 | ||||
| 010 | 682559-5@141 | 0.83 | 1.00 | |
| Netsnoer 2x1.50 4.0mtr | ||||
| 011 | 695123-3@141 | 21.70 | 26.26 | |
| Tussenplaat | ||||
| 012 | 413076-2@141 | 1.43 | 1.73 | |
| Borgring | ||||
| 013 | 259039-2@141 | 0.83 | 1.00 | |
| Magnetische Bus Rt0700 A | ||||
| 014 | 688117-5@141 | 2.80 | 3.39 | |
| Veerring 6 | ||||
| 015 | 267756-0@141 | 0.83 | 1.00 | |
| Labyrint Ring GA5040C A | ||||
| 016 | 422750-1@141 | 2.21 | 2.67 | |
| Veld | ||||
| 017 | 626598-5@141 | 28.73 | 34.76 | |
| Isolatiedeksel | ||||
| 018 | 417237-6@141 | 0.83 | 1.00 | |
| Borgplaat | ||||
| 019 | 344871-8@141 | 0.83 | 1.00 | |
| Tapschroef 4x70 | ||||
| 020 | 266258-3@141 | 0.83 | 1.00 | |
| Kogellager 627ddw | ||||
| 021 | 210045-2@141 | 3.22 | 3.90 | |
| Sluitring 7 | ||||
| 022 | 253823-7@141 | 0.83 | 1.00 | |
| Isolatiering | ||||
| 023 | 681656-4@141 | 0.83 | 1.00 | |
| Anker | ||||
| 024 | 515208-8@141 | 70.18 | 84.92 | |
| Waaier 57 | ||||
| 025 | 240033-5@141 | 4.08 | 4.94 | |
| Sluitring 12 | ||||
| 026 | 253084-9@141 | 0.83 | 1.00 | |
| Tandwielhuisdeksel | ||||
| 027 | 317359-1@141 | 10.81 | 13.08 | |
| Kogellager 6001zz | ||||
| 028 | 211148-5@141 | 8.46 | 10.24 | |
| Borgring S-12 | ||||
| 029 | 961052-5@141 | 0.83 | 1.00 | |
| Borgveer 12 | ||||
| 030 | 233901-9@141 | 2.80 | 3.39 | |
| Sluitring 12 | ||||
| 031 | 253052-2@141 | 0.83 | 1.00 | |
| Tandwiel 9 | ||||
| 032 | 227429-7@141 | 12.58 | 15.22 | |
| Sluitring 6 | ||||
| 033 | 253077-6@141 | 0.83 | 1.00 | |
| Borgring S-6 | ||||
| 034 | 961002-0@141 | 0.83 | 1.00 | |
| Schakelaarhandel | ||||
| 035 | 417186-7@141 | 1.72 | 2.08 | |
| Schakelaarknop | ||||
| 036 | 417813-6@141 | 0.83 | 1.00 | |
| Label "makita" | ||||
| 037 | 819080-3@141 | 3.83 | 4.63 | |
| Motorhuis | ||||
| 038 | 418512-3@141 | 14.90 | 18.03 | |
| Koolborstelhouder | ||||
| 039 | 643760-7@141 | 3.22 | 3.90 | |
| Zelftapper Pt 3x10 | ||||
| 040 | 266256-7@141 | 0.83 | 1.00 | |
| Kooborstelset CB-318 | ||||
| 041 | 191978-9@141 | 8.46 | 10.24 | |
| Achterdeksel | ||||
| 042 | 417183-3@141 | 8.46 | 10.24 | |
| Tapschroef 4x18 | ||||
| 043 | 265A48-7@141 | 0.90 | 1.09 | |
| Toerenregelcircuit | ||||
| 044 | 631492-8@141 | 46.31 | 56.04 | |
| Koolborstelhouder | ||||
| 045 | 643760-7@141 | 3.22 | 3.90 | |
| Zelftapper Pt 3x10 | ||||
| 046 | 266256-7@141 | 0.83 | 1.00 | |
| Handgreep set | ||||
| 048 | 183692-1@141 | 23.75 | 28.74 | |
| Drukveer 4 | ||||
| 049 | 233071-4@141 | 0.83 | 1.00 | |
| Sluitmoer M14x45mm | ||||
| 050 | 224577-3@141 | 5.32 | 6.44 | |
| Afstandring 3,0mm | ||||
| 051 | 331661-8@141 | 2.97 | 3.59 | |
| Afstandring 6,0mm | ||||
| 052 | 331662-6@141 | 2.97 | 3.59 | |
| Bus | ||||
| 053 | 257732-2@141 | 9.96 | 12.05 | |
| Binnenflens 42mm | ||||
| 054 | 224415-9@141 | 3.35 | 4.05 | |
| As | ||||
| 055 | 324393-4@141 | 28.85 | 34.91 | |
| Labyrint ring | ||||
| 056 | 415300-9@141 | 1.21 | 1.46 | |
| Inbusbout 4x16 | ||||
| 057 | 266437-3@141 | 0.83 | 1.00 | |
| Lagerhuis alu | ||||
| 058 | 318334-0@141 | 21.70 | 26.26 | |
| O-ring 52 | ||||
| 059 | 213673-2@141 | 0.83 | 1.00 | |
| Kogellager 6201dw1 | ||||
| 060 | 211129-9@141 | 7.44 | 9.00 | |
| Lager borgring 19-33 | ||||
| 061 | 285841-7@141 | 1.72 | 2.08 | |
| Tandwiel 35 | ||||
| 062 | 227430-2@141 | 17.90 | 21.66 | |
| Pen | ||||
| 063 | 256459-1@141 | 1.21 | 1.46 | |
| O-ring 6 | ||||
| 064 | 213048-5@141 | 0.83 | 1.00 | |
| Tandwielhuis | ||||
| 065 | 153488-4@141 | 19.80 | 23.96 | |
| Kogellager 607llb | ||||
| 065A | 211021-9@141 | 4.58 | 5.54 | |
| Drukveer 8 | ||||
| 066 | 233072-2@141 | 0.83 | 1.00 | |
| Blokkeerknopkap | ||||
| 067 | 417236-8@141 | 0.83 | 1.00 | |
| Tapschroef 4x28 | ||||
| 068 | 266257-5@141 | 0.83 | 1.00 | |
| Stopring E-4 | ||||
| 069 | 961011-9@141 | 0.83 | 1.00 | |
| Loopwiel 6x20mm | ||||
| 070 | 257227-5@141 | 4.58 | 5.54 | |
| Geen informatie beschikbaar, niet bestelbaar | ||||
| 071 | 961014-3@141 | |||
| slijpkap | ||||
| 072 | 153685-2@141 | 53.39 | 64.60 | |
| Schaalverdeling | ||||
| 072A | 816397-5@141 | 2.08 | 2.52 | |
| Kraagas Sg1250 | ||||
| 073 | 324392-6@141 | 5.22 | 6.32 | |
| Torsieveer 11 | ||||
| 074 | 231655-2@141 | 1.51 | 1.83 | |
| Tapschroef Ct 4x25 | ||||
| 075 | 266040-0@141 | 0.83 | 1.00 | |
| Stofkap | ||||
| 076 | 418390-1@141 | 6.16 | 7.45 | |
| Naamplaat | ||||
| 077 | 850945-0@141 | 2.80 | 3.39 | |
| Stofafzuigadapter sleuvenzaag | ||||
| 078 | 416741-2@141 | 3.95 | 4.78 | |
| O-ring 30 | ||||
| 079 | 213423-5@141 | 0.83 | 1.00 | |
| Beschermkap | ||||
| 080 | 183718-9@141 | 41.78 | 50.55 | |
| Inbusbout M8x45 | ||||
| 081 | 922466-3@141 | 1.06 | 1.28 | |
| Borgring S-10 | ||||
| 082 | 257408-1@141 | 0.95 | 1.15 | |
| Label "makita" | ||||
| 083 | 819064-1@141 | 0.83 | 1.00 | |
| Voetplaat | ||||
| 084 | 317723-6@141 | 31.62 | 38.26 | |
| Inbusbout M8x65 | ||||
| 085 | 922487-5@141 | 1.01 | 1.22 | |
| Sluitring 8 | ||||
| 086 | 941202-8@141 | 0.83 | 1.00 | |
| Nokkenschijf | ||||
| 087 | 223145-9@141 | 4.08 | 4.94 | |
| Front greep | ||||
| 088 | 417665-5@141 | 10.84 | 13.12 | |
| Moer M6 4-k | ||||
| 090 | 252185-0@141 | 1.43 | 1.73 | |
| Bitklem | ||||
| 091 | 344391-2@141 | 0.83 | 1.00 | |
| Inbusbout M5X30 Sg1250 | ||||
| 092 | 922251-4@141 | 0.83 | 1.00 | |
| Sluitring 8 | ||||
| 093 | 941202-8@141 | 0.83 | 1.00 | |
| Inbusbout M8x40 | ||||
| 094 | 922462-1@141 | 0.83 | 1.00 | |
| Indicator Sg1250 | ||||
| 095 | 345364-8@141 | 1.72 | 2.08 | |
| Veerring 6 A | ||||
| 096 | 253903-9@141 | 0.83 | 1.00 | |
| Bus 7Mm Sg1250 | ||||
| 097 | 257731-4@141 | 1.72 | 2.08 | |
| Schroef 6x33 | ||||
| 098 | 251897-2@141 | 3.22 | 3.90 | |
| Dunne sluitring 10 | ||||
| 099 | 253310-6@141 | 0.83 | 1.00 | |
| Veerring 10 | ||||
| 100 | 267783-7@141 | 0.83 | 1.00 | |
| Dunne sluitring 10 | ||||
| 101 | 253310-6@141 | 0.83 | 1.00 | |
